? 18V drive，low current，high power conversion efficiency
? Thin encapsulation with heat sink，efficient heat dissipation
? Applicable to LED bulb，downlights，module etc. cost-effective
? Rated power：0.6W
| Parameter | Symbol | Rating |
| Forward Current | IF | 35mA |
|
Pulse Forwards Current*2 |
IFP | 100mA |
|
Reverse Voltage |
VR |
30V |
|
Working Temperature |
TOPR |
-30~+85℃ |
|
Storage Temperature |
TSTG |
-40~+100℃ |
| Color | Part number | Color temp（K） | CRI Ra Min |
I F( mA) TEST |
Φv（l m） Typ. |
VF( V) Typ. |
| Natural white | FM-SP3528WNS-460R | 5600-6500 | 70 | 30 | 65 | 19.2 |
|
Neutral white |
FM-SP3528WDS-460R-R80 | 3700-4200 | 80 | 30 | 60 | 19.2 |
|
Warm white |
FM-SP3528WLS-460R-R80 |
2800-3200 |
80 |
30 |
58 |
19.2 |
