?Ceramic substrate，stable performance，high reliability.
?Application of infrared photography and security system，with a wavelength of 850nm,940nm.
? Rated power：0.5-2w.
| Parameter | Symbol | Rating |
|
Working Temperature |
TOPR |
-30~+85℃ |
|
Storage Temperature |
TSTG |
-40~+100℃ |
| Part number | Color Temp（K） |
I F( mA) TEST |
Radiation Power（mW） ( mW) |
I R( μA) Max*1 |
| FP-3535I R-BS-SBC | 850 | 350 | 204 | 1.5 |
| FP-3535I R-BS-SCC | 850 | 350 | 220 | 1.5 |
